Marin Bolinas Ridge 27.5

Marin Bolinas Ridge 27.5

$700.00 NZD
$700.00 NZD
Sale Sold out
Tax included.
Size

The Bolinas Ridge series is perfectly suited for recreational riders wishing to explore singletrack and dirt trails with a mountain bike built for real trails. The Bolinas Ridge 1 is built around a Series 1 6061 aluminum frame with a replaceable derailleur hanger and an integrated headset. Spec’d with a trail munching 100mm travel SR Suntour XCE suspension fork, all-conditions low maintenance Power CX7 mechanical disc brakes, durable double wall rims, serviceable cassette freehubs and a trail proven 3x7 speed Shimano Tourney drivetrain. The Bolinas Ridge has a growing wheel size for the best fit and performance for all rider heights, with sizes XS, SM and MD fitted with 27.5” wheels and 29” platforms on sizes MD, LG, and XL.

  • 6061 alloy frame with trail focused geometry
  • 100mm travel SR Suntour XCE front fork
  • Power CX7 mechanical disc brakes
  • 3x7 speed Shimano Tourney drivetrain
  • XS, SM and MD fitted with 27.5” wheels
  • MD, LG and XL fitted with 29” wheels
Bottom bracket: Sealed Cartridge Bearings, Square Taper
Brakes: Power CX7 Mechanical Disc, Shimano Pad Compatible
Chain: KMC Z-8.3
Crankset: Alloy Crank, Steel Chainrings, 42/34/24T
Derailleur rear: Shimano Tourney, 7-Speed
Fork: SR Suntour XCE Disc, 100mm Travel, Preload Adjustment, 46mm Offset
Frame: Series 1 6061 Aluminum, 27.5”/29" Wheels, Low Standover, 68mm BB shell, 135mm Forged Dropouts
Freewheel: SunRace 7-Speed, 11-34T Cassette
Grip: Marin MTB, Closed End
Handlebar: Marin 31.8 Riser, 12mm Rise, 780mm Width
Handlebar stem: Marin Alloy, 31.8mm, 45mm
Headset: FSA No.10-P
Hubs: Forged Alloy, 32H
Pedals: Nylon Platform
Rim: Marin, Double Wall Alloy
Rotor front: 160mm Rotor
Rotor rear: 160mm Rotor
Saddle: Marin MTB
Season: 2022
Seat post: Marin Alloy, 27.2mm
Spokes: 14g Black Stainless Steel
Tyre front: MTB, 27.5" x 2.25" on sizes XS,SM,MD, 29" x 2.25" on sizes LG,XL,XXL
Tyre rear: MTB, 27.5" x 2.25" on sizes XS,SM,MD, 29" x 2.25" on sizes LG,XL,XXL
Wheel size: 27.5" (650b)




 XS / 13" S / 15" M (27.5) / 17" M (29) / 17" L / 19" XL / 20.5" XXL / 22"
Stack 580.8 585.5 590 616 620.5 625 630
Reach 400 415 430 430 445 465 475
Headtube Angle 68.5° 68.5° 68.5° 68° 68° 68° 68°
Headtube Length 100 105 110 110 115 120 125
Seattube Angle 74° 74° 74° 74° 74° 74° 74°
Seattube Length 330 381 431 431 481 520 559
Toptube Effective 566.5 583 599.2 606.6 623 644.2 655.6
BB Height 307 307 307 311.5 311.5 311.5 311.5
BB Drop 48 48 48 61 61 61 61
Chainstay 430 430 430 455 455 455 455
Wheelbase 1084.5 1101.3 1118.2 1160 1177 1199 1210
Standover Height 649.11 663.03 706.24 716.44 744.89 773.66 806.58
Fork Offset 46 46 46 46 46 46 46
Seatpost Diameter 27.2 27.2 27.2 27.2 27.2 27.2 27.2
Handlebar Width 780 780 780 780 780 780 780
Stem Length 45 45 45 45 45 45 45
Crank Length 170 170 175 175 175 175 175

All lengths in millimeters
