COMMENCAL META HT AM ORIGIN HERITAGE GREEN

The META HT V2 focuses on simplicity. Here, there's no rear suspension - it's all about the fundamentals of riding. Its geometry and frame construction provide maximum sensations. Power transmission is optimized to facilitate pedaling. It accompanies you whatever your mood of the moment.

• Frame

  2022 Meta HT AM - 29''/27'' on S / M & 29''/29'' on L / XL
  Alloy 6061, triple butted tubes, T4, T6.

• Fork

  ROCKSHOX 35 Silver R, 150 mm travel
  29", Coil, rebound, Boost (15 x 110 mm), 44 mm offset

• Headset

  ACROS ZS44 / ZS56
  Alloy cups, sealed bearings

• Stem

  RIDE ALPHA Freeride 40
  40 mm extension, 31,8 mm

• Handlebar

  RIDE ALPHA R20 on S - RIDE ALPHA R27 on M / L / XL
  31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL

• Grips

  RIDE ALPHA DH
  Ultra-soft compound, single clamp, black

• Brakes

  SRAM Level, 2 pistons, Hydraulic disc brake
  Rotors: SRAM G2 CleanSweep 200 / 180 mm, 6-bolt

• Shifters

  SRAM SX Eagle
  12s

• REAR DERAILLEUR

  SRAM SX Eagle
  12s

• Bottom bracket

  SRAM BSA
  Threaded

• Crankset

  SRAM X1 1000 Eagle, 170 mm crank arms, DUB, Boost
  Chainring: SRAM X1 1000 Eagle, 32t, Narrow-Wide

• Chain

  SRAM NX Eagle
  12s

• Cassette

  SRAM PG-1210
  12s, 11-50t

• Rims

  E13 LG1 EN Base
  REAR: 27.5'', 32h, 30 mm inner width on S / M - 29'', 32h, 30 mm inner width on L / XL - FRONT: 29'', 32h, 30 mm inner width on S / M / L / XL

• Hubs

  Rear: FORMULA DC-348A - Front: FORMULA DC-711
  Rear: 32h, sealed bearings, 12 x 148 mm, Shimano Hyperglide - Front: 32h, sealed bearings, 15 x 110 mm

• Spokes/nipples

  SAPIM Leader
  J-Bend 2.0 mm, stainless, with Nylok, black

• Tyres

  Rear: MAXXIS Dissector - Front: MAXXIS Dissector
  Rear: 27.5'' x 2.6’', dual compound, EXO, Tubeless Ready on S / M - 29'' x 2.6’', dual compound, EXO, Tubeless Ready, on L / XL - Front: 29" x 2.6", dual compound, EXO, Tubeless Ready on S / M / L / XL

• Seat post

  RIDE ALPHA
  31,6 mm, 400 mm on S/M, 450 mm on L/X

• Saddle

  SDG Bel Air V3
  140 mm width, Steel rails

• Weight

  14,2 kg / 31.30 lb
  Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.

• Pedals included

  No

• Colour

  Heritage Green
  Matte Finish

• Accessories

  Chainstay protector, seatstay protector
